Description
Features
1. It is suitable for 16S 60V li-ion battery.
2. With functions of protection from voltage, current and temperature detection, including over-current, overvoltage, under-voltage and short circuit protection.
3. According to the customer request we can develop PCM in different sizes and structures.
Electrical Characteristic (Ta=25 ºC)
No. |
Test Item |
Min. |
Typ. |
Max |
Unit |
1 |
Input Charging Voltage |
67 |
67.2 |
67.4 |
V |
2 |
Input Charging Current |
|
15 |
17 |
A |
3 |
Output Discharging Current |
|
40 |
42 |
A |
4 |
Over-Current Discharging Protection |
85 |
100 |
115 |
A |
5 |
Current Consumption |
10 |
15 |
25 |
uA |
6 |
Balance Current |
40 |
45 |
50 |
mA |
7 |
Balance Voltage |
4.18 |
4.20 |
4.22 |
V |
8 |
Over-Charge Protection Voltage |
4.18 |
4.20 |
4.25 |
V |
9 |
Over-Charge Protection Voltage Release |
4.05 |
4.10 |
4.15 |
V |
10 |
Over-Charge Protection Voltage Delay Time |
1.0 |
1.5 |
2.0 |
S |
11 |
Over-Discharge Protection Voltage |
2.67 |
2.75 |
2.83 |
V |
12 |
Over-Discharge Protection Voltage Release |
2.9 |
3.0 |
3.1 |
V |
13 |
Over-Discharge Protection Voltage Delay Time |
1.0 |
1.5 |
2.0 |
S |
14 |
Short Circuit Protection Release |
Remove the load |
|||
15 |
Impedance |
|
8 |
15 |
mΩ |
16 |
Operating Temperature |
-15 |
+25 |
+60 |
ºC |
17 |
Storage Temperature |
-20 |
+25 |
+70 |
ºC |
