15S 30A 55V BMS Li-ion Battery ANN EBike Balanced UK seller UK stock


15M30A-01



No.

Test Item

Min.

Typ.

Max

Unit

1

Input Charging Voltage

62.8

63

63.2

V

2

Input Charging Current



30

35

A

3

Output Discharging Current



30

35

A

4

Over-Current Discharging Protection

80

95

105

A

5

Current Consumption

15

25

32

uA

6

Balance Current

44

49

54

mA

7

Balance Voltage

4.16

4.18

4.20

V

8

Over-Charge Protection Voltage

4.17

4.20

4.25

V

9

Over-Charge Protection Voltage Release

4.05

4.10

4.15

V

10

Over-Charge Protection Voltage Delay Time

0.5

1.0

2.0

S

11

Over-Discharge Protection Voltage

2.67

2.75

2.83

V

12

Over-Discharge Protection Voltage Release

2.9

3.0

3.1

V

13

Over-Discharge Protection Voltage Delay Time

0.5

1.0

2.0

S

14

Short Circuit Protection Release

Remove the load

15

Impedance



8

15

16

Operating Temperature

-15

+25

+60

ºC

17

Storage Temperature

-20

+25

+70

ºC


 002 003

15M30A-03
